(API 624 Additional High Temperature Version)
Key Specifications / Features
The ASTM A182 F51 Lift Check Valve Plant specializes in manufacturing high-quality lift check valves that adhere to ASME B16.34 standards. These valves are constructed with a duplex stainless steel body, providing superior corrosion resistance and durability. With a nominal diameter of DN80 (3 inches) and a pressure rating of PN160 (Class 900 LB), they are designed to handle high-pressure applications. The valves feature raised face (RF) flanged ends for secure and reliable installation.
- Model no.: MV-20250626-FSCV-01
- Hits: 0
- Categories: Forged Steel Check Valve
- Tags: ASME B16.34 Check Valve, Lift Check Valve, ASTM A182 F51 Check Valve
Detail Information
Product Name: ASTM A182 F51 Lift Check Valve
Type: Lift Check Valve
Design Standard: ASME B16.34
Body Material: ASTM A182 F51
Size: DN80, 3 Inch
Pressure: PN160, Class 900 LB
End Connection: RF Flanged
Face to Face Standard: ASME B16.10
Test & Inspection Standard: API 598
Certificates: TA-Luft, ISO 15848-1, API 622, ect
Product Range
Body Materials:
Carbon Steel: ASTM A105, A105N
Stainless Steel: ASTM A182 F304/F304L, F316/F316L
Duplex Steel: ASTM A182 F51
Gasket & Packing Material: Graphite/PTFE
Size Range: 1/2-3 Inch, DN15-DN80
Pressure Range: Class 150-2500 LB, PN16-PN420
End Connection: Welded, Flanged (RF, RTJ)
Temperature Range: -29°C to 429°C
Medium: Water, Oil & Gas
The packing used in forged valves is the M800 series graphite packing,
with a graphite carbon content exceeding 99% and a sulfur content below 50 PPM.
The dynamic leakage rate, as tested according to API 622, is less than 12 PPM.
The static leakage rate is below 6 PPM.
All the gaskets used are low-emission gaskets certified by TÜV Rheinland TA-LUFT.
Type Test Report for 2-Inch Gate Valve
According to ISO 15848-1 at 400°C
Type Test Report for 1-Inch Globe Valve
According to ISO 15848-1 at 400°C
Type Test Report for 3/4-Inch Gate Valve
According to ISO 15848-1 at 400°C
The 0.5-inch forged steel gate valve in accordance with API 602 is tested for an ISO 15848-2 Class A leakage rate below 50 PPMV, using the M600 model low emission packing.
The 1-inch forged steel gate valve, in accordance with API 602, is tested for an ISO 15848-2 Class A leakage rate of less than 50 PPMV, using the M600 model low-emission packing.
The 1.5-inch forged steel globe valve, in accordance with API 602, is tested for an ISO 15848-2 Class A leakage rate of less than 50 PPMV, using the M800 model low-emission packing.
The API 624 test for a 2-inch forged steel gate valve in accordance with API 602 uses the M600 model low-emission packing.
