(API 624 Additional High Temperature Version)
Key Specifications / Features
The ASTM A216 WCC Swing Check Valve adheres to stringent API 6D and BS 1868 standards. This 12-inch (DN300) valve features a robust carbon steel body and high-performance 13Cr trim, ensuring durability and reliability in demanding applications. Rated at Class 600 LB and PN100, it is designed for high-pressure systems. The valve is equipped with RTJ flanged ends for secure and leak-free connections. This swing check valve is an excellent choice for industries requiring efficient and dependable flow control solutions.
- Model No.: MV-20250624-CSCV-01
- Hits: 4
- Categories: Cast Steel Check Valve
- Tags: ASTM A216 WCC Check Valve, Swing Check Valve, 12 Inch Check Valve
Detail Information
Product Name: ASTM A216 WCC Swing Check Valve
Type: Swing Check Valve
Design Standard: API 6D, BS 1868
Body Material: ASTM A216 WCC
Trim Material: 13Cr
Size: 12 Inch, DN300
Pressure: Class 600 LB, PN100
End Connection: RTJ Flanged
Face to Face Standard: ASME B16.10
Test & Inspection Standard: API 598
Certificates: TA-Luft, ISO 15848-1, API 622, ect
Product Range
Body Materials: ASTM A216 WCB, WCC, A351 CF3, CF8, A352 LCC, LCB, etc
Gasket & Packing Material: Graphite, PTFE
Size Range: 2-60 Inch, DN50-DN1500
Pressure Range: Class 150-2500 LB, PN16-PN420
End Connection: RF, RTJ, BW
Temperature Range: -29°C to 429°C
Medium: Water, Oil, Gas, etc
The packing used in cast steel valves is the M800 series graphite packing,
with a graphite carbon content exceeding 99% and a sulfur content below 50 PPM.
The dynamic leakage rate, as tested according to API 622, is less than 12 PPM.
The static leakage rate is below 6 PPM.
All the gaskets used are low-emission gaskets certified by TÜV Rheinland TA-LUFT
ISO 15848-1 Valve Tested Case Example: NPS4 Class 300 Valve
4-inch 300 LB Globe Valve: ISO 15848-1 Test at Ambient Temperature for 205 Cycles, High Leakage Rate of 1.8×10−7, Maximum Body Leakage at 11.6 PPMV
API 624 Valve Test Case 1: 12-inch 150 LB Gate Valve
12-inch 150 LB Gate Valve
API 624 Test
Maximum Packing Leakage: 46.7 PPMv
API 624 Valve Test Case 2： 12-inch 600 LB Gate Valve
12-inch 600 LB Gate Valve
API 624 Testing
Maximum packing leakage: 32 ppmv
Fire Test Certification of Valve Packing
Fire Test Report and Certification for 4-inch Gate Valve with M800 Packing
ISO 15848-1 Valve Tested Case Example: NPS12 Class 300 Valve
12-inch 300 LB Gate Valve
ISO 15848-1 Test at Ambient Temperature for 205 Cycles
High Leakage Rate: 1.6×10−6
Maximum Body Leakage: 7.7 PPMV
The API 624 test for the API 600 WCB 12-inch 150 LB gate valve utilized an M600 low-emission graphite packing set.
The ISO 15848-2 Type A test for the API 600 WCB 2-inch 150 LB gate valve, which requires emissions below 50 PPMV, was conducted using an M600 low-emission graphite packing set.
