ASTM A182 F304L Cryogenic Globe Valve, BS 6364, 2 IN, CL600

Compliant with TA-LUFT/ISO 15848-1/API 624
(API 624 Additional High Temperature Version)

Key Specifications / Features

The ASTM A182 F304L Cryogenic Globe Valve ensures minimal leakage in low-temperature environments. Manufactured from forged stainless steel, it meets BS 6364 standards for reliability and durability. With a 2-inch (DN50) size, Class 600 LB pressure rating, and PN100 compatibility, this valve offers superior strength and corrosion resistance. The Outside Screw & Yoke (OS&Y) design enhances smooth operation, making it ideal for precise flow control in demanding cryogenic systems that require low leakage and long-lasting performance.

Model no.: MV-20250403-CGLV-01
Hits: 0
Categories: Cryogenic Globe Valve
Tags: ASTM A182 F304L Globe Valve, Cryogenic Globe Valve, BS 6364 Globe Valve

Request a quote

Detail Information

Product Name: ASTM A182 F304L Cryogenic Globe Valve
Design Standard: BS 6364
Body Material: ASTM A182 F304L
Size: 2 Inch, DN50
Pressure: Class 600 LB, PN100
End: RF
Operation: Handwheel
Features: Outside Screw & Yoke (OS&Y)

Product Range

Size Range: NPS 1/2-6 Inch, DN15-DN150
Pressure Class: Class 150-2500 LB
Operating Temperature: -196°C to 200°C
Structural Features: Bolted Bonnet (BB), Integral Extended Bonnet
Body Material: ASTM A105N, A350 LF2, LF3, A182 F11, F5, F22, F304, F304L, F316, F316L, F321, F304H, F316H, F321H, F51, F53, F55, F91, F92, F347, 310S, Incoloy 800H, Incoloy 600, Incoloy 625, etc

Applicable Standards

Design: ASME B16.34, BS 6364
Inspection & Testing: API 598, BS 6364
Marking: MSS SP-25
Pressure-Temperature Rating: ASME B16.34
Fugitive Emission Compliance: API 624, ISO 15848
Face-to-Face Dimensions: ASME B16.10
End-to-End Dimensions: Manufacturer Standard or ASME B16.10
