(API 624 Additional High Temperature Version)
Key Specifications / Features
The Forged Stainless Steel Gate Valve is a high-performance valve designed to meet the stringent requirements of industrial applications. It is manufactured from ASTM A182 F316/F316L stainless steel, ensuring excellent corrosion resistance and durability. The valve adheres to API 602 standards, with a 2-inch (DN50) size and a high-pressure rating of 2500 LB (PN420). It features a bolted bonnet design for enhanced structural integrity and flanged ends for easy installation and maintenance. The low-emission feature ensures environmental compliance and safety.
- Model no.: MV-20250606-FSGTV-04
- Hits: 1
- Categories: Forged Steel Gate Valve
- Tags: ASTM A182 F316L Gate Valve, API 602 Gate Valve, ASTM A182 F316 Gate Valve
Detail Information
Product Name: ASTM A182 F316/F316L Gate Valve, Dual Grade Stainless Steel
Design Standard: API 602
Body Material: ASTM A182 F316/F316L
Size: 2 Inch, DN50
Pressure: Class 2500 LB, PN420
Operation: Handwheel
End Connection: Flanged Ends
Certificates: TA-Luft, ISO 15848-1, API 622, ect
Standards:
Flanged Ends: ASME B16.5
Face to Face: ASME B16.10
Test & Inspection: API 598
Product Range
Body Materials: Forged Carbon, Stainless, Alloy Steel
Gasket & Packing Material: Graphite/PTFE
Size Range: 1/2-32 Inch (DN15-DN800)
End Connection: Flanged, BW
Pressure Range: Class 150-2500 LB (PN16-PN420)
Working Temperature: -29°C to 429°C
Application: Water, Oil & Gas
The packing used in forged valves is the M800 series graphite packing,
with a graphite carbon content exceeding 99% and a sulfur content below 50 PPM.
The dynamic leakage rate, as tested according to API 622, is less than 12 PPM.
The static leakage rate is below 6 PPM.
All the gaskets used are low-emission gaskets certified by TÜV Rheinland TA-LUFT.
Type Test Report for 2-Inch Gate Valve
According to ISO 15848-1 at 400°C
Type Test Report for 1-Inch Globe Valve
According to ISO 15848-1 at 400°C
Type Test Report for 3/4-Inch Gate Valve
According to ISO 15848-1 at 400°C
The 0.5-inch forged steel gate valve in accordance with API 602 is tested for an ISO 15848-2 Class A leakage rate below 50 PPMV, using the M600 model low emission packing.
The 1-inch forged steel gate valve, in accordance with API 602, is tested for an ISO 15848-2 Class A leakage rate of less than 50 PPMV, using the M600 model low-emission packing.
The 1.5-inch forged steel globe valve, in accordance with API 602, is tested for an ISO 15848-2 Class A leakage rate of less than 50 PPMV, using the M800 model low-emission packing.
The API 624 test for a 2-inch forged steel gate valve in accordance with API 602 uses the M600 model low-emission packing.
