(API 624 Additional High Temperature Version)
Key Specifications / Features
The Micro Resistance Slow Closing Check Valve is a high-quality valve designed for industrial applications. It features a ductile iron QT450 body, ensuring durability and strength. With a size of DN100 (4 inches) and a pressure rating of PN16 (Class 150 LB), it is suitable for systems requiring robust performance. The flanged ends facilitate easy installation and integration into existing pipelines. This valve is ideal for preventing backflow and ensuring smooth, controlled fluid movement, making it a reliable choice for various industrial plants.
- Model no.: MV-20250630-CSCV-04
- Hits: 0
- Categories: Cast Steel Check Valve
- Tags: Micro Resistance Check Valve, QT450 Check Valve, Slow Closing Check Valve
Detail Information
Product Name: Micro Resistance Slow Closing Check Valve
Body Material: DI QT450
Size: DN100, 4 Inch
Pressure: PN16, Class 150 LB
End Connection: Flanged
Product Range
Size Range: DN50-DN800, 2-32 Inch
Pressure Range: PN16-PN150, Class 150-900 LB
Body Material: Ductile Iron
Suitable Medium: Clear water, sewage, seawater, etc.
Applicable Temperature: ≤120°C
