ASTM A182 F316L Globe Valve, API 602, BS 1873, 1 Inch, CL800
Compliant with TA-LUFT/ISO 15848-1/API 624
(API 624 Additional High Temperature Version)

Key Specifications / Features

The China ASTM A182 F316L Globe Valve features a forged steel construction, complying with API 602 and BS 1873 standards. With a 1-inch (DN25) size, Class 800 LB rating, and PN130 pressure rating, it is designed for high-performance applications with low leakage. The valve includes an outside screw and yoke (OS&Y) design, bolted bonnet for secure sealing, and BW (butt-weld) ends for reliable installation.

Detail Information

Product Name: ASTM A182 F316L Globe Valve
Features: OS&Y, Bolted Bonnet
Design Standard: API 602, BS 1873
Body Material: ASTM A182 F316L
Size: 1 Inch, DN25
Pressure: Class 800 LB, PN130
End: BW
Operation: Handwheel

Product Range

Size Range: NPS 1/2-6 Inch, DN15-DN150
Pressure Range: Class 150-4500 LB
Body Material: ASTM A105, A105N, A350 LF2, A182 F11, F22, F91, F304/304L, F316/316L, F321, F347, F51, Monel, Inconel etc.
Product Structure: Bolted Bonnet (BB), Welded Bonnet (WB), Pressure Seal Bonnet (PSB)

Applicable Standards

Design: API 602, BS 1873, ISO 15761, ASME B16.34
Inspection & Testing: API 598
Marking: MSS SP-25
P/T Rating: ASME B16.34
Face to Face: ASME B16.10
End to End: Manufacturer Std or ASME B16.10
Socket Welding: ASME B16.11M800 Graphite Packings
Screwed Ends: ASME B1.20.1
Flanged: ASME B16.5
Butt Welding: ASME B16.25


The packing used in forged valves is the M800 series graphite packing,

with a graphite carbon content exceeding 99% and a sulfur content below 50 PPM.

The dynamic leakage rate, as tested according to API 622, is less than 12 PPM.

The static leakage rate is below 6 PPM.



All the gaskets used are low-emission gaskets certified by TÜV Rheinland TA-LUFT.

TÜV Rheinland TA-LUFT Certified Low-emission Gaskets

M12 Spiral Wound Gasket TÜV Rheinland TA-LUFT Certification

2-inch Gate Valve









                                    Type Test Report for 2-Inch Gate Valve

                                    According to ISO 15848-1 at 400°C









2-inch Gate Valve ISO 15848-1 Type Test Report for 400°C

                                   1-Inch Globe Valve











                                    Type Test Report for 1-Inch Globe Valve

                                    According to ISO 15848-1 at 400°C













Type Test Report for 1-Inch Globe Valve According to ISO 15848-1 at 400°C

3/4 Inch Gate Valve







                                    Type Test Report for 3/4-Inch Gate Valve

                                    According to ISO 15848-1 at 400°C

















Type Test Report for 0.75-Inch Gate Valve According to ISO 15848-1 at 400°C
